Infusion Logistics course available from Bound Tree EDU

One of the newest infusion pumps on the market, The Sapphire™ Multi-Therapy.

Be empowered with a complete infusion system that delivers multiple therapies, for home care, hospitals and ambulatory settings. Sapphire™ drives the future of infusion care.

Features:

• Compact, lightweight device that is intuitive and easy to use
• Consistent accuracy with robust performance
• Single solution fits all, for any infusion need
• Software-driven and built-in adaptability
• Dimensions: 5.63in H x 3.78in W x 1.93 in D
• Weight (w/o battery): 14.7 ounces
• Accuracy:
  • ±2.5% under normal conditions (per IEC60601-2-24 standard)
• Battery:
  • Rechargeable Li-Ion battery 7.4V, 1960 mA/h, 24 hrs @ 125 mL/h (with a fully charged battery and backlight Off)
  • Recharge time: up to 6 hrs (when pump is not in operation)
• Flow rate:
  • 0.1 – 99.9 mL/h in increments of 0.1 mL/h
  • 100 – 999 mL/h in increments of 1 mL/h

Kit Includes:

• (1) Q Core Medical Sapphire™ Infusion Pump
• (1) Q Core Medical Sapphire™ Infusion Pump AC Power Cord

This cable is used to communicate from the Q Core Sapphire™ Infusion Pump Kit (Multi-Therapy or Epidural) to a computer when performing preventative maintenance.

Features:

• For Use With: Sapphire™ Infusion Pump Kit (Multi-Therapy or Epidural)

This cable is designed to help expedite the software preventative maintenance of the Q Core Sapphire Infusion Pump (Multi-Therapy or Epidural). This adapter allows you to update four Sapphire infusion pumps at one time.

Features:

• Expedite maintenance on four (4) pumps at once
• For use with Q Core Sapphire Infusion Pump (Multi-Therapy or Epidural)
• Weight: 4lb
• Dimensions: 10in x 10in x 10in
• Condition: New

This Type-B AC Power Cord is intended for use with the Sapphire™ Infusion Pumps by Eitan.

Features:

• For Use With: Sapphire™ Infusion Pumps

This is the AC Power cord/adapter for the Sapphire Infusion Pump.

Features:

• Dimensions: 8in L x 8in W x 8in H
• Weight: 1lb
• Compatible with Sapphire Infusion Pump

The Sapphire Pump EMS Carry Case is intended for use with the Sapphire Infusion Pumps.

Features:

• Color: Blue
• For use with Sapphire Infusion Pump

Please note contents are not included.

This slip and impact-resistant thermoplastic rubber protective cover is designed specifically for the Sapphire Infusion Pump in clinics, hospitals and transport environments. This product is proven to increase the durability and longevity of the Sapphire pump, while maintaining its portable size and convenient storage.

Features:

• Color: Blue
• Material: Thermoplastic Rubber
• For Use With: Sapphire IV Pump
• Loading door and charging port access
• Hang tab is sized to facilitate different hanging variations
• Includes Sapphire Pump protective case, lanyard and carabiner

This is a great option for a padded and cleanable bag for the Sapphire EMS infusion pump. The bag includes D rings and snap buttons, making it fully functional.

Features:

• Dimensions: 5.9in L x 3.9in W x 2.4in H
• Weight: 0.20lb
• Color: Blue
• Material: Polyester, Polyurethane
• (2) D rings for connections
• Padded material for protection
• Screen protection
• Easy access to plug and channels

*Please note contents are not included.

This is the travel case for the Sapphire™ Infusion Pump (Multi-Therapy or Epidural). It includes foam cut-outs for the Mini Cradle, Infusion Pump, and other accessories.

Features:

• Color: Blue
• For Use With: Sapphire™ Infusion Pumps
• Weight: 5lb

Please note, items pictured in travel case are not included.

This is the Medical Sapphire Infusion Pump cradle and is compatible with Sapphire Infusion Pump.

Features:

• Dimensions: 8in L x 8in W x 8in H
• Weight: 1lb
• Compatible with Sapphire Infusion Pump

This is the Medical Sapphire Infusion Pump cradle and is compatible with Sapphire Infusion Pump.

Features:

• Dimensions: 10in L x 10in W x 10in H
• Weight: 3lb
• Compatible with Sapphire Infusion Pump
• with Splitter

The Sapphire IV Pump for Sapphire Infusion Pump is double unit configuration. An integrated swivel feature allows end-users to secure the self-contained assembly to vertical or horizontal tubing. A quick-release allows for rapid installation or removal of Sapphire units as needed. Each configuration includes an extendable IV Pole.

Features:

• Universal Clamp for an array of pole diameters up to 1.5in
• Allows rapid install and removal of Sapphire IV Pumps  to equipment poles
• For use with Sapphire Infusion Pump
• 6.55in H x 12.25in W x 2in D

The Sapphire™ Mounting System is designed to facilitate the use of multiple Sapphire™ infusion pumps while saving valuable bed-side space and providing power consolidation. The Mounting System is designed to accommodate three Mini Cradles, and charge three infusion pumps via a single power outlet, all attached to an IV pole via a single clamp. The Mounting System can also accommodate the use of a single PCA Lockbox 250 when mounted on the right-hand Mini Cradle among the three.

Please note mount not rated for transport.

Features:

• For Use With: Sapphire™ Infusion Pump

Preventative Maintenance (One Time Service):

• Diagnostic check of device’s CPU
• Test power supply and all parameters (if applicable)
• Test system’s internal clock
• Operational check of all system functions per OEM specifications
• Full Biomed report
• Phone support
• Complimentary cleaning of each unit upon return
• Free return shipping

Premium Service Plan:

• Annual preventative maintenance
• Full coverage on all parts and labor for repairs/maintenance
• Full Biomed report with every service, repair or preventative maintenance
• Rental unit for each unit sent in for service, repair or preventative maintenance
• Phone Support
• Complimentary cleaning of each unit upon return
• Free return shipping on all service, repairs or preventative maintenance

Coverage includes:

• Annual preventative maintenance/calibration with test report
• Parts and labor for repairs due to defect in manufacturing or workmanship
• Replacement of batteries at OEM recommended intervals
• Does not include: device abuse, negligence, or force majeure


Premium Service Plan:

• Annual preventative maintenance
• Full coverage on all parts and labor for repairs/maintenance
• Full Biomed report with every service, repair or preventative maintenance
• Rental unit for each unit sent in for service, repair or preventative maintenance
• Phone Support
• Complimentary cleaning of each unit upon return
• Free return shipping on all service, repairs or preventative maintenance

Coverage includes:

• Annual preventative maintenance/calibration with test report
• Parts and labor for repairs due to defect in manufacturing or workmanship
• Replacement of batteries at OEM recommended intervals
• Does not include: device abuse, negligence, or force majeure


Premium Service Plan:

• Annual preventative maintenance
• Full coverage on all parts and labor for repairs/maintenance
• Full Biomed report with every service, repair or preventative maintenance
• Rental unit for each unit sent in for service, repair or preventative maintenance
• Phone Support
• Complimentary cleaning of each unit upon return
• Free return shipping on all service, repairs or preventative maintenance

Coverage includes:

• Annual preventative maintenance/calibration with test report
• Parts and labor for repairs due to defect in manufacturing or workmanship
• Replacement of batteries at OEM recommended intervals
• Does not include: device abuse, negligence, or force majeure


The Sapphire FasTest PM an on-site maintenance servicing tool for the Sapphire infusion pump platform. The kit enables you to:

• Quickly and easily conduct full maintenance verification tests
• Receive an immediate certification report to help maintain compliance
• Reduce maintenance costs and equipment downtime

Benefits:

• Standardize pump testing with a dedicated tool and software for independence and control of the maintenance process
• Makes pump maintenance easier than ever. An easy and intuitive solution providing step-by-step, guided navigation for the ability to easily learn the software and handling for quick maintenance
• Improves efficiency by moving annual PM tests in-house
• Helps streamline maintenance processes by deploying an efficient maintenance system that is fast, cost effective and sustainable.
• FasTest PM kits are reusable

Specifications:

• Average PM Run Time: < 5 minutes
• Calibration Verification Process: Air detection, flow accuracy, occlusion sensing
• Sequence of Tests: Visual inspection, safety features testing, calibration verification
• FasTest PM Certificate report automatically generated. Can be printed or saved. The report includes the following information:
  • Device SW version
  • Certification kit S/N
  • Test date
  • Technician name
  • Visual inspection & safety features test results Air Detection, accuracy & occlusion test results

Kit contains:

500 mL fluid bag & administration set with

• 1800 mm tubing
• Spike
• Syringe
• Back check valve
• Y-connector
• T-connector
• Administration cassette
• Slide clamp
• Sleeve
• Fluid bag cap
